The truck detects turning angles and gently lowers speed ahead of the turn. This keeps handling stable, cornering smooth, and helps prevent tipping or load shift.
Built-in Mast Tilt Control and automatic reach damping work together to keep the truck balanced. Movements like mast tilt and reach are auto-tuned for faster, safer pallet handling.
An intelligent system automatically adjusts reach, tilt, and sideshift speeds. This fine control helps operators work faster while keeping movements smooth and natural.
Both mast and cabin are engineered to give the clearest possible all-round visibility. This helps operators work confidently and safely while maintaining high productivity.
A single ergonomic joystick controls seven key truck functions, including lift, lower, reach, and tilt. This lets operators work naturally and reduces effort during busy shifts.
The truck detects turning angles and gently lowers speed ahead of the turn. This keeps handling stable, cornering smooth, and helps prevent tipping or load shift.
Built-in Mast Tilt Control and automatic reach damping work together to keep the truck balanced. Movements like mast tilt and reach are auto-tuned for faster, safer pallet handling.
An intelligent system automatically adjusts reach, tilt, and sideshift speeds. This fine control helps operators work faster while keeping movements smooth and natural.
Both mast and cabin are engineered to give the clearest possible all-round visibility. This helps operators work confidently and safely while maintaining high productivity.
A single ergonomic joystick controls seven key truck functions, including lift, lower, reach, and tilt. This lets operators work naturally and reduces effort during busy shifts.
Model |
---|
RB16N3 |
RB16N3H |
RB16N3HS |
RB20N3 |
RB20N3H |
RB20N3HX |
RB25N3H |
Power Source |
---|
Electric |
Electric |
Electric |
Electric |
Electric |
Electric |
Electric |
Operator Type |
---|
Seated |
Seated |
Seated |
Seated |
Seated |
Seated |
Seated |
Load Capacity (kg) |
---|
1600 kg |
1600 kg |
1600 kg |
2000 kg |
2000 kg |
2000 kg |
2500 kg |
Load Centre Distance (mm) |
---|
600 mm |
600 mm |
600 mm |
600 mm |
600 mm |
600 mm |
600 mm |
Load Distance - Axle to Forkface (mm) |
---|
600* mm |
600* mm |
600* mm |
600* mm |
600* mm |
600* mm |
600* mm |
Wheelbase (mm) |
---|
1448 mm |
1420 mm |
1420 mm |
1530 mm |
1530 mm |
1530 mm |
1630 mm |
Model |
---|
RB16N3 |
RB16N3H |
RB16N3HS |
RB20N3 |
RB20N3H |
RB20N3HX |
RB25N3H |
Unladen Weight (kg) |
---|
3590 kg |
4320 kg |
4220 kg |
4140 kg |
4550 kg |
5200 kg |
4600 kg |
Axle Loading w/ Maximum Load - front/rear (kg) |
---|
2000 / 1190 kg |
2360 / 1760 kg |
2556 / 1930 kg |
2290 / 1450 kg |
2400 / 1750 kg |
2790 / 2410 kg |
2400 / 2000 kg |
Axle Loading no Load - front/rear (kg) |
---|
1750 / 3040 kg (Mast Forward) |
1900 / 3820 kg (Mast Forward) |
2041 / 3965 kg (Mast Forward) |
2040 / 3700 kg (Mast Forward) |
2050 / 4100 kg (Mast Forward) |
2280 / 4920 kg (Mast Forward) |
2100 / 4100 kg (Mast Forward) |
Model |
---|
RB16N3 |
RB16N3H |
RB16N3HS |
RB20N3 |
RB20N3H |
RB20N3HX |
RB25N3H |
Tyres |
---|
Vul (Vulkollan) |
Vul (Vulkollan) |
Vul (Vulkollan) |
Vul (Vulkollan) |
Vul (Vulkollan) |
Vul (Vulkollan) |
Vul (Vulkollan) |
Front Tyre Dimensions |
---|
355 x 155 mm |
355 x 155 mm |
355 x 155 mm |
355 x 155 mm |
355 x 155 mm |
355 x 155 mm |
355 x 155 mm |
Rear Tyre Dimensions |
---|
285 × 105 mm |
285 × 105 mm |
285 × 105 mm |
285 × 105 mm |
285 × 105 mm |
285 × 105 mm |
285 × 105 mm |
No. of Wheels |
---|
2 / 1 x |
2 / 1 x |
2 / 1 x |
2 / 1 x |
2 / 1 x |
2 / 1 x |
2 / 1 x |
Truck Width (centre of tyres, front) mm |
---|
1128 mm |
1128 / 1255 mm |
1157 mm |
1128 / 1255 mm |
1128 / 1255 mm |
1255 mm |
1255 mm |
