| Model |
|---|
| PBV20N3 |
| PBV25N3 |
| PBF20N3R |
| PBF25N3R |
| PBF20N3S |
| PBF25N3S |
| Power Source |
|---|
| Electric |
| Electric |
| Electric |
| Electric |
| Electric |
| Electric |
| Operator Type |
|---|
| Pedestrian / Stand-on |
| Pedestrian / Stand-on |
| Pedestrian / Stand-on |
| Pedestrian / Stand-on |
| Pedestrian / Stand-on |
| Pedestrian / Stand-on |
| Load Capacity (kg) |
|---|
| 2000 kg |
| 2500 kg |
| 2000 kg |
| 2500 kg |
| 2000 kg |
| 2500 kg |
| Load Centre Distance (mm) |
|---|
| 600 mm |
| 600 mm |
| 600 mm |
| 600 mm |
| 600 mm |
| 600 mm |
| Load Distance - Axle to Forkface (mm) |
|---|
| 975 mm |
| 975 mm |
| 975 mm |
| 975 mm |
| 975 mm |
| 975 mm |
| Wheelbase (mm) |
|---|
| 1437 mm |
| 1437 mm |
| 1437 mm |
| 1437 mm |
| 1437 mm |
| 1437 mm |
| Model |
|---|
| PBV20N3 |
| PBV25N3 |
| PBF20N3R |
| PBF25N3R |
| PBF20N3S |
| PBF25N3S |
| Unladen Weight (kg) |
|---|
| 750 kg |
| 750 kg |
| 820 kg |
| 820 kg |
| 800 kg |
| 800 kg |
| Axle Loading w/ Maximum Load - front/rear (kg) |
|---|
| 1015 / 1742 kg |
| 1128 / 2129 kg |
| 1216 / 1691 kg |
| 1270 / 2110 kg |
| 1202 / 1688 kg |
| 1193 / 2107 kg |
| Axle Loading no Load - front/rear (kg) |
|---|
| 570 / 187 kg |
| 570 / 187 kg |
| 648 / 169 kg |
| 648 / 169 kg |
| 634 / 166 kg |
| 643 / 166 kg |
| Model |
|---|
| PBV20N3 |
| PBV25N3 |
| PBF20N3R |
| PBF25N3R |
| PBF20N3S |
| PBF25N3S |
| Tyres |
|---|
| Vul (Vulkollan) |
| Vul (Vulkollan) |
| Vul (Vulkollan) |
| Vul (Vulkollan) |
| Vul (Vulkollan) |
| Vul (Vulkollan) |
| Front Tyre Dimensions |
|---|
| 235 × 75 mm |
| 235 × 75 mm |
| 235 × 75 mm |
| 235 × 75 mm |
| 235 × 75 mm |
| 235 × 75 mm |
| Rear Tyre Dimensions |
|---|
| 150 × 60 mm |
| 150 × 60 mm |
| 150 × 60 mm |
| 150 × 60 mm |
| 150 × 60 mm |
| 150 × 60 mm |
| No. of Wheels |
|---|
| 4 / 1× + 2 |
| 4 / 1× + 2 |
| 4 / 1× + 2 |
| 4 / 1× + 2 |
| 4 / 1× + 2 |
| 4 / 1× + 2 |
| Truck Width (centre of tyres, front) mm |
|---|
| 520 mm |
| 520 mm |
| 520 mm |
| 520 mm |
| 520 mm |
| 520 mm |
| Truck Width (centre of tyres, rear) mm |
|---|
| b5 - 175 mm |
| b5 - 175 mm |
| b5 - 175 mm |
| b5 - 175 mm |
| b5 - 175 mm |
| b5 - 175 mm |
