EDiA EM (3 Wheels)

Counterbalance Forklifts, Electric, New
The Mitsubishi EDiA EM FB20N2 is a 2.0-tonne, 4-wheel electric forklift offering stability and intelligent performance. Equipped with features like AutoBoost for additional power when needed, and a mini steering wheel with a floating armrest for operator comfort, it ensures efficient and safe operations. The truck’s design minimizes fatigue and reduces the risk of repetitive strain injuries.

360° Steering

Enables smooth, continuous turning without the stop-start of a 3-point turn. Saves time on every manoeuvre and reduces strain on the load—making operation faster, safer, and more stable.

Sensitive Drive System+ (SDS+)

This driver-assist system adapts to the operator’s input in real time, adjusting performance to boost both productivity and safety.

AutoBoost

The truck automatically delivers extra acceleration and torque when it senses the need for more power.

Intelligent Cornering System

Automatically adjusts the truck’s speed based on steering angle, helping improve site safety, boost productivity, and cut down on tyre wear.

Automatic Hill Hold

AHH stops the truck from rolling back on steep ramps, even when fully loaded. This makes loading and unloading quicker, safer, and helps protect both the operator and the goods.

Red Dot Design Award Winner

The truck’s modern design, advanced features, and top-tier ergonomics stood out to the expert judges.

Mini steering wheel with floating armrest

The adjustable control setup is built for comfort, especially during long shifts. It helps reduce fatigue, keeps drivers more focused, and lowers the risk of strain injuries, cutting down on time off and related costs.

Li-ion Battery

This option supports fast charging with low maintenance, eliminating the need for spare batteries or time lost on changeovers.

Passive Sway Control

The chassis absorbs mast sway, giving operators more control and confidence when lifting to higher levels.

Electric differential lock

When switched on, the electric differential lock boosts traction by turning both front wheels together. It can be set to activate automatically at low speeds or limited steering angles.

Dual joysticks

The ergonomic dual joysticks allow lift and tilt at the same time, with a solid grip that works well even when wearing gloves.

AutoBoost

The truck detects when extra power is needed and automatically boosts acceleration and torque to match.

KEY FEATURES

360° Steering

Enables smooth, continuous turning without the stop-start of a 3-point turn. Saves time on every manoeuvre and reduces strain on the load—making operation faster, safer, and more stable.

Mini steering wheel with floating armrest

The adjustable control setup is built for comfort, especially during long shifts. It helps reduce fatigue, keeps drivers more focused, and lowers the risk of strain injuries, cutting down on time off and related costs.

Li-ion battery

This option supports fast charging with low maintenance, eliminating the need for spare batteries or time lost on changeovers.

Dual joysticks

The ergonomic dual joysticks allow lift and tilt at the same time, with a solid grip that works well even when wearing gloves.

AutoBoost

The truck automatically delivers extra acceleration and torque when it senses the need for more power.

KEY FEATURES

This truck is perfect for...

The EDiA EM FB20N2 suits businesses requiring stable and efficient material handling, such as distribution centres and manufacturing plants. Its ergonomic features and intelligent systems make it a reliable choice for operations focused on operator well-being and productivity.

Detailed specification

Model
FB14N2T
FB16CN2T
FB16N2T
FB18CN2T
FB18N2T
FB20N2T
Power Source
Electric
Electric
Electric
Electric
Electric
Electric
Operator Type
Seated
Seated
Seated
Seated
Seated
Seated
Load Capacity (kg)
1400 kg
1600 kg
1600 kg
1800 kg
1800 kg
2000 kg
Load Centre Distance (mm)
500 mm
500 mm
500 mm
500 mm
500 mm
500 mm
Load Distance - Axle to Forkface (mm)
343 mm
343 mm
343 mm
343 mm
343 mm
358 mm
Wheelbase (mm)
1320 mm
1320 mm
1428 mm
1320 mm
1428 mm
1428 mm
Model
FB14N2T
FB16CN2T
FB16N2T
FB18CN2T
FB18N2T
FB20N2T
Unladen Weight (kg)
2790 kg
2966 kg
2949 kg
3156 kg
3119 kg
3342 kg
Axle Loading w/ Maximum Load - front/rear (kg)
3688 / 502 kg
4015 / 551 kg
4020 / 529 kg
4351 / 605 kg
4333 / 586 kg
4711 / 631 kg
Axle Loading no Load - front/rear (kg)
1394 / 1396 kg
1393 / 1573 kg
1476 / 1474 kg
1401 / 1754 kg
1471 / 1649 kg
1509 / 1833 kg
Model
FB14N2T
FB16CN2T
FB16N2T
FB18CN2T
FB18N2T
FB20N2T
Tyres
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
Front Tyre Dimensions
18 × 7-8
18 × 7-8
18 × 7-8
18 × 7-8
18 × 7-8
200 / 50-10
Rear Tyre Dimensions
140 / 55-9
140 / 55-9
140 / 55-9
140 / 55-9
140 / 55-9
140 / 55-9
No. of Wheels
2 × / 2
2 × / 2
2 × / 2
2 × / 2
2 × / 2
2 × / 2
Truck Width (centre of tyres, front) mm
930 mm
930 mm
930 mm
930 mm
930 mm
938 mm
Truck Width (centre of tyres, rear) mm
174 mm
174 mm
174 mm
174 mm
174 mm
174 mm

Which truck is right for you?

EDIAEM33-34MRANGE-FULL-01-L

FB14N2T

1.4 Tonne
Tonnes
3 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
EDIAEM33-34SHEET-FULL-01-P-min

FB16CN2T

1.6 Tonne
Tonnes
3 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
EDIAEM33-34MRANGE-FULL-01-L

FB16N2T

1.6 Tonne
Tonnes
3 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
EDIAEM33-34SHEET-FULL-01-P-min

FB18CN2T

1.8 Tonne
Tonnes
3 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
EDIAEM33-34MRANGE-FULL-01-L

FB18N2T

1.8 Tonne
Tonnes
3 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
EDIAEM33-34SHEET-FULL-01-P-min

FB20N2T

2.0 Tonne
Tonnes
3 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre

Jofson have supported us for years. Their service is consistent, reliable, and personal — which is exactly what we expect from our own suppliers. That kind of long-term commitment is why we keep coming back.

Jamie Fell

Transport Manager

Whatever you need, we can deliver

Frequently Asked Questions

It can lift up to 2.0 tonnes, making it a strong choice for a wide range of warehouse and logistics tasks.
The 3-wheel design offers superior manoeuvrability, especially in narrow aisles, allowing tight turns and smooth handling.
Yes. While built for indoor environments, it’s also capable outdoors on smooth surfaces, thanks to its sealed components and all-weather design.
It includes features like automatic curve control, adaptive performance settings, and an ergonomic cabin to reduce fatigue and support safer, more efficient operation.
