By placing the operator fully inside the truck, they’re better shielded from impacts. The compact design also allows the truck to navigate tighter aisles with ease.
Alongside its stable chassis, built-in systems help maintain control - automatically slowing acceleration during sharp turns and reducing speed when forks are raised above 1.7 metres.
This optional control feature allows the operator to face forward when travelling long distances with forks trailing - improving comfort and reducing fatigue. (Optional)
Telescopic forks enable double-deep stacking, the ability to transport two pallets or long goods, and extended reach for easier loading and unloading from one side of lorries and conveyors.
The truck senses the turning angle and adjusts speed early - helping ensure smooth, stable, and safer cornering.
The optional lithium-ion battery offers quick charging with minimal maintenance - eliminating the need for spare batteries or manual swap-outs.
Straddle legs positioned outside the pallet allow handling of closed-bottom pallets and specialised loads. The open space also accommodates various attachments like clamps, spikes, and rollers. Standard widths are 855 mm or 1055 mm, with other options available.
This option allows the truck to turn smoothly in one motion, without the stop-start action of a 3-point turn. It saves time, protects loads, and improves overall handling. (Optional)
By placing the operator fully inside the truck, they’re better shielded from impacts. The compact design also allows the truck to navigate tighter aisles with ease.
Alongside its stable chassis, built-in systems help maintain control, automatically slowing acceleration during sharp turns and reducing speed when forks are raised above 1.7 metres.
Telescopic forks enable double-deep stacking, the ability to transport two pallets or long goods, and extended reach for easier loading and unloading from one side of lorries and conveyors.
The optional lithium-ion battery offers quick charging with minimal maintenance, eliminating the need for spare batteries or manual swap-outs.
This option allows the truck to turn smoothly in one motion, without the stop-start action of a 3-point turn. It saves time, protects loads, and improves overall handling. (Optional)
Model |
---|
SBR12N2TF |
Power Source |
---|
Electric |
Operator Type |
---|
Stand-in |
Load Capacity (kg) |
---|
1200 kg |
Load Centre Distance (mm) |
---|
600 mm |
Load Distance - Axle to Forkface (mm) |
---|
714 mm |
Wheelbase (mm) |
---|
1540 mm |
Model |
---|
SBR12N2TF |
Unladen Weight (kg) |
---|
2068 kg |
Axle Loading w/ Maximum Load - front/rear (kg) |
---|
1468 / 1800 kg |
Axle Loading no Load - front/rear (kg) |
---|
1448 / 620 kg |
Model |
---|
SBR12N2TF |
Tyres |
---|
Vul (Vulkollan) |
Front Tyre Dimensions |
---|
250 × 105 mm |
Rear Tyre Dimensions |
---|
150 × 55 mm |
No. of Wheels |
---|
2 / 1× + 2 |
Truck Width (centre of tyres, front) mm |
---|
651 mm |
Truck Width (centre of tyres, rear) mm |
---|
850 / 1050 mm |
