Gives operators full control with a spacious cabin, adjustable seat, and easy-reach controls.
Thanks to a low 215 mm step height and wide entry for quicker access.
Work with your operator’s style to boost picking speed and accuracy.
Offers generous storage space and a layout designed for maximum picking efficiency.
MaxVision mast helps operators avoid racking and stock damage.
Easy battery access and component layout keeps downtime low.
Strong construction protects both operators and equipment over time.
Cuts energy use by 12% with no loss in performance.
Wide-coverage sensor replaces a dead man's switch and lets operators move freely.
Rust-proof axles allow dependable operation in temperatures down to 0 °C.
Gives operators full control with a spacious cabin, adjustable seat, and easy-reach controls.
Work with your operator’s style to boost picking speed and accuracy.
Easy battery access and component layout keeps downtime low.
Strong construction protects both operators and equipment over time.
Rust-proof axles allow dependable operation in temperatures down to 0 °C.
Model |
---|
OPBM10P (DUPLEX) |
OPBM10P (TRIPLEX FREE LIFT) |
Power Source |
---|
Electric |
Electric |
Operator Type |
---|
Stand-on |
Stand-on |
Load Capacity (kg) |
---|
1000 kg |
1000 kg |
Load Centre Distance (mm) |
---|
600 mm |
600 mm |
Load Distance - Axle to Forkface (mm) |
---|
125 mm |
204 mm |
Wheelbase (mm) |
---|
1568 mm |
1568 mm |
Model |
---|
OPBM10P (DUPLEX) |
OPBM10P (TRIPLEX FREE LIFT) |
Unladen Weight (kg) |
---|
2050 + ( 96 x h12) kg |
2260 + ( 91.5 x h12) kg |
Axle Loading w/ Maximum Load - front/rear (kg) |
---|
1110 / 2800 kg |
1210 / 2910 kg |
Axle Loading no Load - front/rear (kg) |
---|
1660 / 1250 kg |
1790 / 1330 kg |
Model |
---|
OPBM10P (DUPLEX) |
OPBM10P (TRIPLEX FREE LIFT) |
Tyres |
---|
Vul (Vulkollan) |
Vul (Vulkollan) |
Front Tyre Dimensions |
---|
250 × 105 mm |
250 × 105 mm |
Rear Tyre Dimensions |
---|
150 × 55 mm |
150 × 55 mm |
No. of Wheels |
---|
8 / 1x |
8 / 1x |
Truck Width (centre of tyres, front) mm |
---|
806 / 906 / 1006 mm |
906 / 1006 mm |
