Low step height (160 mm) and wide entry (603 mm) make getting on and off faster and safer.
Smart design includes extra storage and space to keep tools and goods close to hand during order picking.
MaxVision mast and open layout give operators better visibility - helping avoid damage to goods and racking.
Steel wraparound bumper protects both operator and truck - extending lifespan in demanding environments.
ECO mode cuts energy use by 12% while keeping up with your workload.
The Operator Presence Sensor covers the full platform floor - no need for a dead man's switch and more freedom to move.
With EasyLift, operators can adjust pallet height to reduce strain and work more comfortably.
Optional high-speed mode boosts travel from 9 km/h to 12 km/h - ideal for longer runs.
Battery rollers and a discharge indicator make swapping and checking batteries quick and hassle-free.
AC motor delivers fast acceleration and high speed - even under load - with quiet, controlled handling.
Low step height (160 mm) and wide entry (603 mm) make getting on and off faster and safer.
MaxVision mast and open layout give operators better visibility - helping avoid damage to goods and racking.
Steel wraparound bumper protects both operator and truck, extending lifespan in demanding environments.
Optional high-speed mode boosts travel from 9 km/h to 12 km/h, ideal for longer runs.
AC motor delivers fast acceleration and high speed, even under load, with quiet, controlled handling.
Model |
---|
OPBL10P (WITHOUT EASYLIFT) |
OPBL10P (WITH EASYLIFT) |
Power Source |
---|
Electric |
Electric |
Operator Type |
---|
Stand-on |
Stand-on |
Load Capacity (kg) |
---|
1000 kg |
1000 kg |
Load Centre Distance (mm) |
---|
600 mm |
600 mm |
Load Distance - Axle to Forkface (mm) |
---|
100 mm |
120 mm |
Wheelbase (mm) |
---|
1371 mm |
1371 mm |
Model |
---|
OPBL10P (WITHOUT EASYLIFT) |
OPBL10P (WITH EASYLIFT) |
Unladen Weight (kg) |
---|
2500 kg |
2650 kg |
Axle Loading w/ Maximum Load - front/rear (kg) |
---|
470 / 2030 kg |
480 / 2170 kg |
Axle Loading no Load - front/rear (kg) |
---|
990 / 510 kg |
990 / 660 kg |
Model |
---|
OPBL10P (WITHOUT EASYLIFT) |
OPBL10P (WITH EASYLIFT) |
Tyres |
---|
Vul (Vulkollan) |
Vul (Vulkollan) |
Front Tyre Dimensions |
---|
250 × 105 mm |
250 × 105 mm |
Rear Tyre Dimensions |
---|
120 × 115 mm |
120 × 115 mm |
No. of Wheels |
---|
2 / 1x |
2 / 1x |
Truck Width (centre of tyres, rear) mm |
---|
674 mm |
674 mm |
