Improves safety by cutting off hydraulic and drive functions if the operator leaves the seat for more than 2 seconds. Standard PIN access stops unauthorised use.
Fully sealed underside protects the engine from damage by debris like shrink-wrap. It also cuts noise and helps prevent dust-related safety issues.
Pedals are set at the ideal angle for easy use and better control - without straining the operator’s legs.
The low noise and vibration from the powertrain help reduce fatigue, keeping operators comfortable and focused.
The advanced electronic control system includes: Two adjustable travel speeds Low gear lock for safer use at height or on uneven ground Soft power mode to cut wheelspin, save tyres, and lower fuel use
To protect the engine, the system responds in two steps if it overheats: first it slows the machine down, then it shuts it off to prevent damage.
The fully floating powertrain is built to last. It gives strong, responsive performance with smooth, efficient control.
For added safety, LED lights come as standard. They’re brighter than halogen, turn on automatically, and never need replacing if still working - all with no extra power use.
Improves safety of work area as use of the machine is restricted to authorised operators only.
Fitted to all LPG models as part of Mitsubishi’s safety-first approach. Delivers low fuel use, fewer emissions, and strong performance.
Fully sealed underside protects the engine from damage by debris like shrink-wrap. It also cuts noise and helps prevent dust-related safety issues.
To protect the engine, the system responds in two steps if it overheats: first it slows the machine down, then it shuts it off to prevent damage.
For added safety, LED lights come as standard. They’re brighter than halogen, turn on automatically, and never need replacing if still working, all with no extra power use.
Improves safety of work area as use of the machine is restricted to authorised operators only.
Fitted to all LPG models as part of Mitsubishi’s safety-first approach. Delivers low fuel use, fewer emissions, and strong performance.
Model |
---|
FG40N3 |
FG45N3 |
FG50CN3 |
FG50N3 |
FG55N3 |
Power Source |
---|
LPG |
LPG |
LPG |
LPG |
LPG |
Operator Type |
---|
Seated |
Seated |
Seated |
Seated |
Seated |
Load Capacity (kg) |
---|
4000 kg |
4500 kg |
5000 kg |
5000 kg |
5500 kg |
Load Centre Distance (mm) |
---|
500 mm |
500 mm |
500 mm |
600 mm |
600 mm |
Load Distance - Axle to Forkface (mm) |
---|
577 mm |
577 mm |
582 mm |
602 mm |
602 mm |
Wheelbase (mm) |
---|
1850 mm |
2000 mm |
2000 mm |
2150 mm |
2150 mm |
Model |
---|
FG40N3 |
FG45N3 |
FG50CN3 |
FG50N3 |
FG55N3 |
Unladen Weight (kg) |
---|
6270 kg |
5860 kg |
6780 kg |
7240 kg |
7570 kg |
Axle Loading w/ Maximum Load - front/rear (kg) |
---|
8940 kg / 920 kg |
9680 kg / 1090 kg |
10,570 / 1210 kg |
10,990 kg / 1250 kg |
11,710 kg / 1360 kg |
Axle Loading no Load - front/rear (kg) |
---|
2610 kg / 3250 kg |
2750 kg / 3520 kg |
2870 kg / 3920 kg |
3190 kg / 4050 kg |
3130 kg / 4440 kg |
Model |
---|
FG40N3 |
FG45N3 |
FG50CN3 |
FG50N3 |
FG55N3 |
Tyres |
---|
L (Pneumatic) |
L (Pneumatic) |
L (Pneumatic) |
L (Pneumatic) |
SE (Solid Pneumatic) |
Front Tyre Dimensions |
---|
8.25 - 15 - 14 |
8.25 - 15 - 14 |
300 - 15 - 18 |
300 - 15 - 18 |
300 - 15 / 8.00 |
Rear Tyre Dimensions |
---|
7.00 - 12 - 14 |
7.00 - 12 - 14 |
7.00 - 12 - 14 |
7.00 - 12 - 14 |
7.00 - 12 / 5.00 |
No. of Wheels |
---|
2 x / 2 |
2 x / 2 |
2 x / 2 |
2 x / 2 |
2 x / 2 |
Truck Width (centre of tyres, front) mm |
---|
1175 mm |
1175 mm |
1175 mm |
1175 mm |
1175 mm |
Truck Width (centre of tyres, rear) mm |
---|
1180 mm |
1180 mm |
1180 mm |
1180 mm |
1180 mm |
