Stops hydraulic and drive functions if the operator leaves the seat for more than 2 seconds, helping to keep the area safe. Built-in PIN access stops unauthorised use.
The fully sealed underside helps stop debris like shrink-wrap from getting into the engine. It also lowers noise and prevents dust from creating safety risks.
Built for strength at low RPM, this industrial design delivers maximum torque with less noise and fuel use - giving you high performance without high revs.
The low-maintenance DPF keeps emissions cleaner than Stage V standards. It runs automatically during use, so there’s no need for the driver to clean the filter.
The advanced electronic diesel control gives you two adjustable speeds, a low gear lock for safer handling on rough ground or at height, and a soft-power mode to cut wheelspin, save tyres, and use less fuel.
To protect the engine during overheating, the system responds in two stages - first by slowing the machine down, then by shutting it off if needed.
The full floating powertrain is built to last, delivering strong, responsive performance with smooth, fuel-efficient control.
Mitsubishi fits LED lights as standard for safer operation. They’re fully automatic, brighter than halogen, use no extra power, and never need bulb replacements.
Standard PIN code access helps keep the work area safe by limiting use to authorised operators only.
Stops hydraulic and drive functions if the operator leaves the seat for more than 2 seconds, helping to keep the area safe. Built-in PIN access stops unauthorised use.
The fully sealed underside helps stop debris like shrink-wrap from getting into the engine. It also lowers noise and prevents dust from creating safety risks.
The low-maintenance DPF keeps emissions cleaner than Stage V standards. It runs automatically during use, so there’s no need for the driver to clean the filter.
To protect the engine during overheating, the system responds in two stages, first by slowing the machine down, then by shutting it off if needed.
Mitsubishi fits LED lights as standard for safer operation. They’re fully automatic, brighter than halogen, use no extra power, and never need bulb replacements.
Model |
---|
FD40N3 |
FD45N3 |
FD50CN3 |
FD50N3 |
FD55N3 |
Power Source |
---|
Diesel |
Diesel |
Diesel |
Diesel |
Diesel |
Operator Type |
---|
Seated |
Seated |
Seated |
Seated |
Seated |
Load Capacity (kg) |
---|
4000 kg |
4500 kg |
5000 kg |
5000 kg |
5500 kg |
Load Centre Distance (mm) |
---|
500 mm |
500 mm |
500 mm |
600 mm |
600 mm |
Load Distance - Axle to Forkface (mm) |
---|
577 mm |
577 mm |
582 mm |
602 mm |
602 mm |
Wheelbase (mm) |
---|
1850 mm |
2000 mm |
2000 mm |
2150 mm |
2150 mm |
Model |
---|
FD40N3 |
FD45N3 |
FD50CN3 |
FD50N3 |
FD55N3 |
Unladen Weight (kg) |
---|
5920 kg |
6330 kg |
6850 kg |
7300 kg |
7640 kg |
Axle Loading w/ Maximum Load - front/rear (kg) |
---|
8960 kg / 960 kg |
9710 / 1130 kg |
10,600 / 1250 kg |
11,020 / 1280 kg |
11,740 / 1400 kg |
Axle Loading no Load - front/rear (kg) |
---|
2630 kg / 3290 kg |
2780 kg / 3550 kg |
2900 kg / 3950 kg |
3220 kg / 4080 kg |
3170 kg / 4470kg |
Model |
---|
FD40N3 |
FD45N3 |
FD50CN3 |
FD50N3 |
FD55N3 |
Tyres |
---|
L (Pneumatic) |
L (Pneumatic) |
L (Pneumatic) |
L (Pneumatic) |
SE (Solid Pneumatic) |
Front Tyre Dimensions |
---|
8.25 - 15 - 14 |
8.25 - 15 - 14 |
300 - 15 - 18 |
300 - 15 - 18 |
300 - 15 / 8.00 |
Rear Tyre Dimensions |
---|
7.00 - 12 - 14 |
7.00 - 12 - 14 |
7.00 - 12 - 14 |
7.00 - 12 - 14 |
7.00 - 12 / 5.00 |
No. of Wheels |
---|
2 x / 2 |
2 x / 2 |
2 x / 2 |
2 x / 2 |
2 x / 2 |
Truck Width (centre of tyres, front) mm |
---|
1175 mm |
1175 mm |
1175 mm |
1175 mm |
1175 mm |
Truck Width (centre of tyres, rear) mm |
---|
1180 mm |
1180 mm |
1180 mm |
1180 mm |
1180 mm |
