FB60-120N(H)

Counterbalance Forklifts, Electric, New
The Mitsubishi FB120N is a 12.0-tonne electric forklift offering substantial power with zero emissions. Its rubber-sealed cabin reduces noise and vibrations, providing a comfortable environment for the operator. Features like Four Wheel Steering (available on H models) and rapid battery exchange enhance maneuverability and operational efficiency.​

Comfortable cabin

Cabin noise is kept to just 65 dBA - about the same as a normal conversation - creating a quiet, comfortable space that helps the operator stay focused.

Four Wheel Steering (4WS) (H models only)

This improves grip and control - especially in tight areas - by letting the truck turn quickly and smoothly on the spot. The high manoeuvrability helps boost overall efficiency and productivity.

Low Noise Lift

Loud cabins can lead to operator fatigue. At just 65 dBA, this model has the quietest cabin in its class - helping drivers stay comfortable and alert throughout their shift.

Rapid battery exchange

The dual-battery setup (2 x 48V batteries, one on each side) makes replacements quick and simple - just use a pallet truck or counterbalance to swap them out with ease.

Low seat

The seat height matches that of many IC engine trucks, making it easier for operators to get in and out. This reduces physical strain, helps cut fatigue during shifts, and offers a smoother transition for drivers used to IC models.

KEY FEATURES

Comfortable cabin

Cabin noise is kept to just 65 dB, about the same as a normal conversation, creating a quiet, comfortable space that helps the operator stay focused.

Four Wheel Steering (4WS)

(H models only) This improves grip and control, especially in tight areas, by letting the truck turn quickly and smoothly on the spot. The high manoeuvrability helps boost overall efficiency and productivity.

Low Noise Lift

Loud cabins can lead to operator fatigue. At just 65 dBA, this model has the quietest cabin in its class, helping drivers stay comfortable and alert throughout their shift.

Rapid battery exchange

The dual-battery setup (2 x 48V batteries, one on each side) makes replacements quick and simple, just use a pallet truck or counterbalance to swap them out with ease.

Low seat

The seat height matches that of many IC engine trucks, making it easier for operators to get in and out. This reduces physical strain, helps cut fatigue during shifts, and offers a smoother transition for drivers used to IC models.

KEY FEATURES

This truck is perfect for...

The FB120N is suited for heavy-duty operations in sectors like logistics, shipping, and heavy manufacturing. Its high load capacity and operator-focused design make it a reliable choice for intensive material handling tasks.

Detailed specification

Model
FB60N
FB60NH
FB65N
FB65NH
FB70N
FB70NH
FB80N
FB80NH
FB80N-900
FB80NH-900
FB90N
FB90NH
FB100N
FB100NH
FB120NH
Power Source
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Electric
Operator Type
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Seated
Load Capacity (kg)
6000 kg
6000 kg
6500 kg
6500 kg
7000 kg
7000 kg
8000 kg
8000 kg
8000 kg
8000 kg
9000 kg
9000 kg
10,000 kg
10,000 kg
12,000 kg
Load Centre Distance (mm)
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
600 mm
Load Distance - Axle to Forkface (mm)
650 mm
650 mm
650 mm
650 mm
650 mm
650 mm
700 mm
700 mm
700 mm
700 mm
720 mm
720 mm
720 mm
720 mm
730 mm
Wheelbase (mm)
2250 mm
2250 mm
2250 mm
2250 mm
2250 mm
2250 mm
2550 mm
2550 mm
2550 mm
2630 mm
2550 mm
2550 mm
2630 mm
2630 mm
2980 mm
Model
FB60N
FB60NH
FB65N
FB65NH
FB70N
FB70NH
FB80N
FB80NH
FB80N-900
FB80NH-900
FB90N
FB90NH
FB100N
FB100NH
FB120NH
Unladen Weight (kg)
10,260 kg
10,260 kg
10,430 kg
10,430 kg
10,770 kg
10,770 kg
12,095 kg
12,095 kg
12,095 kg
14,175 kg
13,425 kg
13,425 kg
14,175 kg
14,425 kg
16,105 kg
Axle Loading w/ Maximum Load - front/rear (kg)
14,523 / 1737 kg
14,523 / 1737 kg
15,316 / 1614 kg
15,316 / 1614 kg
16,124 / 1646 kg
16,124 / 1646 kg
18,670 / 1425 kg
18,670 / 1425 kg
18,670 / 1425 kg
20,356 /1819 kg
20,780 / 1645 kg
20,780 / 1645 kg
20,356 / 1819 kg
22,678 / 1747 kg
26,199 / 1906 kg
Axle Loading no Load - front/rear (kg)
5190 / 5070 kg
5190 / 5070 kg
5200 / 5230 kg
5200 / 5230 kg
5240 / 5530 kg
5240 / 5530 kg
6590 / 5505 kg
6590 / 5505 kg
6590 / 5505 kg
7490 / 6685 kg
7120 / 6305 kg
7120 / 6305 kg
7490 / 6685 kg
7660 / 6765 kg
8840 / 7265 kg
Model
FB60N
FB60NH
FB65N
FB65NH
FB70N
FB70NH
FB80N
FB80NH
FB80N-900
FB80NH-900
FB90N
FB90NH
FB100N
FB100NH
FB120NH
Tyres
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
SE (Solid Pneumatic)
Front Tyre Dimensions
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
8.25-15
300-15
300 - 15
300 - 15
355 / 65-15
Rear Tyre Dimensions
22×9-16 23×10-12
22×9-16 23×10-12
22×9-16 23×10-12
22×9-16 23×10-12
22×9-16 23×10-12
22 ×9-16 23 ×10-12
22 ×9-16 23 ×10-12
22 ×9-16 23 ×10-12
315 / 45-12
315 / 45-12
23 ×10-12
23 ×10-12
315 / 45-12
315 / 45-12
315 / 45-12
No. of Wheels
2x / 2
2x / 2
2x / 2
2x / 2
2x / 2
2x / 2
2x / 2
2x / 2
4 ×/2
4 ×/2
4 ×/2
4 ×/2
4 ×/2
4 ×/2
4 ×/2
Truck Width (centre of tyres, front) mm
1305 / 1375 / 1380 mm
1306 / 1375 / 1380 mm
1307 / 1375 / 1380 mm
1308 / 1375 / 1380 mm
1309 / 1375 / 1380 mm
1305 / 1375 / 1380 mm
1306 / 1375 / 1380 mm
1307 / 1375 / 1380 mm
1308 / 1375 / 1380 mm
1309 / 1375 / 1380 mm
1380 mm
1380 mm
1460 mm
1460 mm
1565 mm
Truck Width (centre of tyres, rear) mm
1220 / 1225 mm
1221 / 1225 mm
1222 / 1225 mm
1223 / 1225 mm
1224 / 1225 mm
5240 / 5530 mm
6590 / 5505 mm
6590 / 5505 mm
6590 / 5505 mm
7490 / 6685 mm
1225 mm
1225 mm
1215 mm
1215 mm
1215 mm

Which truck is right for you?

FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB60N

6.0 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB60NH

6.0 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB65N

6.5 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB65NH

6.5 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
500 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB70N

7.0 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB70NH

7.0 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB80N

8.0 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB80NH

8.0 Tonne
Tonnes
4 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB80N-900

8.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB80NH-900

8.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB90N

9.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB90NH

9.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB100N

10.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB100NH

10.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre
FB60-120N(H) Series FB60120NH-34SHEET-FULL-01-L-min

FB100NH

12.0 Tonne
Tonnes
6 Wheels
Wheels
AC-Power
Power Source
600 mm
Load Centre

Jofson have supported us for years. Their service is consistent, reliable, and personal — which is exactly what we expect from our own suppliers. That kind of long-term commitment is why we keep coming back.

Jamie Fell

Transport Manager

Whatever you need, we can deliver

Frequently Asked Questions

The FB120N is a heavy-duty electric forklift with a lift capacity of up to 12 tonne, making it ideal for demanding industrial applications.
Yes. It’s designed for indoor and outdoor performance, with a rugged build, weatherproof components, and high ground clearance to handle tough surfaces.
The FB120N runs on a 120V battery system, offering strong acceleration, long run times, and options for fast, efficient charging to keep productivity high.
Operators benefit from ergonomic controls, a spacious, high-visibility cabin, and advanced safety features like automatic performance adjustments and smooth load handling, even at full capacity.
